REPLACEMENT AND ADJUSTMENT
SM 25
B478/B513/B531
Finisher/
Jogger Unit/
Punch Unit
B478/B51
3/
B531
3.9.2
JOGGER UNI
T PCB
1.
Remove the jogger uni
t from the finisher. (
3.9.1)
2.
Remove the jogger unit control PCB [A] (
x 2,
x 3).
B513R001.W
MF
[A]
902
904
