GUIDE PLATE ADJUSTMENT
B470 4 SM
1.4 GUIDE PLATE ADJUSTMENT
Adjust the guide plate if the holes punched in the covers or slip sheets are not
correctly aligned with holes punched in the other sheets.
1. Open the feed cover.
2. Loosen the screw [A].
3. Push the table [B] left or right to change its position, then tighten the screw.
NOTE: If you want to see the scale [C], you must remove the rear cover and
the support tray.
B470R151.WMF
[A]
[B]
[C]

Ricoh 4051 Specifications

General

Print Technology	Laser
Print Speed (Black)	40 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Duplex Printing	Yes
Mobile Printing	Yes
Copy Speed (Black)	40 cpm
Copy Resolution	600 x 600 dpi
Fax Speed	33.6 Kbps
Functionality	Copy, Print, Scan, Fax
Connectivity	Ethernet, USB
Scan Resolution	600 dpi
