B140 SERIES AND G126 SERVICE MODE
B064 Series/B140 Series/G126 4-68 SM
Finisher B478/B706 Jam Codes
No. Location Related SC Code
141 Entrance Sensor
142 Proof Tray Exit Sensor
143 Exit Sensor
144 Staple Entrance Sensor
145 Exit Sensor after jogging
148 Upper Transport Motor
149 Shift Motor SC733, SC726
150 Jogger Fence Motor SC722
151 Shift Roller or Guide Plate Motor SC732, SC736
153 Stapler Unit SC724, SC738, SC740, SC741
155 Feed Out Belt Motor SC725
156 Punch Hole Motor SC729
158 Z-Fold Jogger Motor (B706 Only)
Mailbox B471 Jam Codes
No. Location Related SC Code
161 Vertical Transport Sensor 1 (CN201) ---
162 Vertical Transport Sensor 2 (CN204) ---
163 Vertical Transport Sensor 3 (CN209) ---
164 Vertical Transport Sensor 4 (CN2014) ---
165 Vertical Transport Sensor 5 (CN2019) ---
Cover Interposer Tray B470 Jam Codes
No. Location Related SC Code
166 Feed or Pull-out Sensor ---
167 Exit Sensor ---
168 Bottom Plate Position Sensor SC750
