REPLACEMENT AND ADJUSTMENT
B478/B513/B531 16
SM
3.5.6 STAPLE
WAST
E HOPPER SENSOR
1.
Open the front door, pull out the stapl
er unit, then remove the rear cover.
2.
Remove the rear cover (
x 2).
3.
Remove the staple waste hopper [A] (
x 1).
4.
Remove the hopper holder [B] (
x 2).
5.
Replace the staple wa
ste hopper sensor [C] (
x 1).
B478R517.W
MF
[B]
[A]
[C]
893
895
