REPLACEMENT AND ADJUSTMENT
SM 19 B478/B513/B531
Finisher/
Jogger Unit/
Punch Unit
B478/B513/
B531
3.7 SHIFT TRAY MOTOR
1. Remove the front door and rear cover ( 3.1).
2. Shift motor [A] ( x 2, x 3)
B478R531.WMF
[A]
