PAPER FEED
SM
6-107
B064 Series/B140 Series/G126
Detailed
Descriptions
By-pass Tray Paper End Detection
When the paper runs out, the paper end feeler
[A] drops through the cutout in the
by-pass paper end sensor [B].
B140D997.W
MF
[A]
[B]
704
706
