PUNCH UNIT (B377)
SM 1-37 B064 Series/B140 Series/G126
Installation
1.7 PUNCH UNIT (B377)
The Punch Unit B377 is installed in the 3000-Sheet Finishers B468/B469/B674.
1.7.1 ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q’ty
1. Punch unit.............................................................................. 1
2. Sensor arm ............................................................................ 1
3. Hopper ................................................................................... 1
4. Step screw ............................................................................. 1
5. Spring .................................................................................... 1
6. Spacer (2 mm) ....................................................................... 1
7. Spacer (1 mm) ....................................................................... 1
8. Tapping screw - M3 x 8.......................................................... 1
9. Tapping screw - M3x 10......................................................... 2
