FUSING UNIT
B064/B140 Series/G126
3-78
SM
3.9.10 STRIPPER
PAWLS
B064 Series
Remove the fusing unit (
3.9.1)
[A]:
Top cover (
x 1)
[B]: Bracket
(
x 1, spring x 1)
[C]:
Inner cover (
x 2)
[D]:
Stripper pawl (
x 1, spring x 3)
B140R801.W
MF
B140R800.W
MF
[C]
[D]
[A]
[B]
251
253
