PAPER FEED
B064 Series/B140 Series/G126
6-104
SM
Tray Side-to-side Positioning
When the feed tray is set in the paper f
eed unit, the side-to-side positioning plate
[A] presses the feed tray against the stopper
[B]. By moving the positioning plate,
the tray position can be changed to adj
ust the side-to-side registration.
B140D992.W
MF
B140D993.
W
MF
[A]
[B]
701
