IEEE802.11B INTERFACE BOARD (WIRELESS LAN) (B582)
SM 7 B659/B581/B596/B582/G377/B609/B735
MFP Options
B659/B581/
B596/B582/
G377/B609/
B735
Troubleshooting Procedure
If there are problems using the wireless LAN, check the following.
1) Check the LED indicator on the wireless LAN card.
2) Check if “IEEE802.11b” is selected in the following user tool:
System Setting> Interface Setting> IEEE 801.11b
NOTE: The “IEEE 801.11b” tab is available only after the IEEE 801.11b card
has been installed.
3) Check if the channel settings are correct.
4) Check if the SSID and WEP are correctly set.
If infrastructure mode is being used,
1) Check if the MAC address is properly set.
2) Check the communication status.
If the communication status is poor, bring the machine closer to the access
point, or check for any obstructions between the machine and the access
point.
If the problem cannot be solved, try changing the channel setting.
