DUPLEX UNIT
B064/B140 Series/G126
3-88
SM
3.10.5 DUPLEX
TRANSPORT
CL
UTCH/JOGGER HP SENSOR
[A]:
Duplex unit release lever (
x 2)
[B]:
Jogger motor bracket (harnesses x 4,
x 3)
[C]:
Transport clutch (harness x 1,
x 1)
•
To release the clutch, push in the
catch pawl on the side of the shaft.
[D]:
Jogger HP sensor (spring x 1,
x 2,
x 1)
B140R814.W
MF
[A]
[C]
[D]
[B]
261
263
