B064 SERIES SERVICE MODE
SM 4-15 B064 Series/B140 Series/G126
Trouble-
shooting
SC300: Image Development System (1)
SC No. Symptom Possible Cause
Charge corona output error 300 D
The feedback voltage from the
charge corona unit is detected too
high 9 times.
• Charge corona power pack defective
• Charge corona harness disconnected
• Poor charge corona unit connection
Charge corona grid leak 303 D
When the high voltage is output to
the corona grid, feedback voltage
exceeds the prescribed value 9
times.
• Charge corona power pack defective
• Charge corona harness disconnected
• Poor charge corona unit connection
Charge corona wire cleaner error 1 305 D
The charge corona wire cleaner
motor is detected:
• Motor locks within 4 s after
switching on, or does not lock
within 30 s.
• Motor locks within 10 s after
reversing, or does not lock within
30 s.
• Charge corona wire cleaner motor
defective
• BCU board defective
Charge corona wire cleaner error 2 306 D
The current at the charge corona
motor is detected less than 83 mA.
• Charge corona wire cleaner motor
connector is defective or not connected.
When SC310~SC317 are logged, the machine halts without displaying the SC number. These SC
codes log an abnormal condition at the potential sensor only when SP3901 (Auto Process Control)
is set to on.
SC No. Symptom Possible Cause
Potential sensor calibration error 1 310 C
During drum potential sensor
calibration, the drum potential
sensor output voltage does not
meet specification when test
voltages (–100V, –800V) are
applied to the drum.
• Potential sensor defective
• Potential sensor harness disconnected
• Potential sensor connector defective or
disconnected
• BCU defective
• OPC connector defective
• Development power pack defective
Potential sensor calibration error 2 311 C
During drum potential sensor
calibration, the drum potential
sensor output voltage does not
meet specification when test
voltages (–100V, –800V) are
applied to the drum.
• Potential sensor defective
• Potential sensor harness disconnected
• Potential sensor connector defective or
disconnected
• BCU defective
• OPC connector defective
• Development power pack defective
To Next Page
