REPLACEMENT AND ADJUSTMENT
B478/B513/B531 14
SM
3.5.4 ENTRANCE
AND
STAPLE
R TRAY ENTRANCE SENSORS
Entrance Sensor
1.
Disconnect the finis
her from the copier.
2.
Remove the sensor bracket [A] (
x 1).
3.
Replace the entrance sensor [B] (
x 1,
x 1).
Stapler Tray Entrance Sensor
1.
Open the front door.
2.
Remove the sensor bracket [C] (
x 1).
3.
Replace the stapler tray entrance sensor [D] (
x 1,
x 1).
B478R513.W
MF
B478R514.W
MF
[B]
[A]
[D]
[C]
891
893
