ADF (B140 SERIES/B064 SERIES)
SM
3-131
B064 Series/B140 Series/G126
Replac
ement
Adjustment
3.13.4 SEPARATION
ROLLER
Open the feed cover.
Feed unit (
3.11.8)
[A]: Separation
roller
cover
•
Use the tip of a screwdriver to push up the cover.
[B]: C-Clamp
(
x 1)
[C]: Separation
roller
[D]:
Torque limiter clutch
B140R870.W
MF
[A]
[B]
[C]
[D]
304
306
