EXTERNA
L
COVERS
SM 1
B473
Large
Capacity Tray
B473
1.
REPLACEMENT AND ADJUSTMENT
1.1 EXTERNAL
COVERS
[A]: Transport
cover
[B]:
Transport cover hinge (
x 1)
[C]:
Rear cover (
x 4)
[D]:
Top cover (
x 1)
[E]:
Right cover (
x 2)
[F]:
Front cover (
x 3)
B473R001.
W
MF
[A]
[B]
[C]
[D]
[E]
[F]
760
762
