IMAGE TRANSFER AND PAPER SEPARATI
ON
B064 Series/B140 Series/G126
6-86
SM
6.10.8 ANTI-CONDENSATION
HEATER
The anti-condensation heater [A] is directly
below the transfer belt drive roller.
This anti-condensation heater turns on aut
omatically at the following times:
•
When the main power switch is turned off
•
When the machine enters auto off mode
B140D969.
W
MF
[A]
683
685
