BOARD STRUCTURE
SM 6-9 B064 Series/B140 Series/G126
Detailed
Descriptions
HDD (Hard Disk Drive)
The HDD has a capacity of 40 GB for image storage. It can store up to
approximately 1,735 copy images, based on the ITU-T No. 4 Chart.
Area Power Off Capacity Control Comment
For image
storage
Store Copy conversion 1735
Copy server, local
storage
For temporary
images
Delete
37124 MB
Copy
Allocated copies
Printer
Scanner
500
100
200
500
Electronic sort,
test printing,
confidential
printing
FileSystem1 Store 500 MB
Print font
download, form
registration
FileSystem2 Delete 500 MB 50 jobs Job spooling area
FileSystem3 Store 2000 MB
Work data of
SmartNet Monitor
for ADMIN.
FileSystem4 Store 2 MB
Area for storing
email addresses
Other Store 174 MB For debugging
An SC is logged if the HDD is abnormal or cannot be detected. After pressing a key
to affirm that you have read the message, the machine shuts down partially but can
still be used. However, some features may not be available.
Note the following important points regarding HDD replacement:
• Replacing the HDD loses all document server documents, and user stamps.
• When the HDD is replaced, the print data (user stamps) must be re-installed, so
bring an IC card holding the print data so it can be downloaded.
• The “Scan to Email” addresses are also lost by HDD replacement. However,
addresses can be backed up SmartNetMonitor.
