STAPLER
B468/B469/B674 36
SM
2.8 STAPLER
2.8.1 STAPLING
MECHANISM
Staple firing is driven by the stapler motor [A] inside the stapler unit. The stapler
hammer [B] fires the stapler [C].
The cartridge set sensor [D] detects the cartridge at the correct position, or logs an
SC if the stapler unit is not
at the correct position.
The stapler end sensor [E] detects t
he staple end condition and logs an SC.
