OVERVIEW
B468/B469/B674 24
SM
2. DET
AILS
2.1 OVERVIEW
1. Proof
Tray
2.
Guide Plate Motor
3. Guide
Plate
4. Shift
Roller
5.
Tray Junction Gate
6. Punch
Unit
7.
Stapler Junction Gate
8. Pre-Stack
Tray
9. Stapler
Unit
10. Pressure Plate Unit*
11. Saddle Stitch Stapler*
12. Folder Plat
e*
13. Lower Tray*
14. Folder Rollers*
15. Upper Tray
16. Jogger Top Fence Motor**
17. Jogger Bottom Fence Motor**
* B468/B674 Only
**
B674 Only
B468D900.W
MF
11
12
2
3
4
5
1
6
7
8
9
10
13
15
14
11
12
16
17
812
814
