DEVELOPMENT AND TONER SUP
PLY
B064 Series/B140 Series/G126
6-68
SM
6.9.4 DEVELOPMENT
BIAS
Development power pack [A] applies –550V thr
ough terminal [B] to the shaft [C] of
the development roller [D]
Bias is also applied to the lower casing
to prevent toner from being attracted back
from the drum.
B140D949.
W
MF
[C]
[B]
[A]
[D]
665
667
