DRUM UNIT
SM
3-45
B06
4 Series/B140 Series/G126
Replac
ement
Adjustment
3.6.15 TONER
COLL
ECTION BOTTLE
1.
Open the front door [A].
2.
Remove the lock pin [B], then pull out t
he toner collection bottle [C] and its base
[D].
3.
Detach the bottle from the
base clamp [E] and replace it.
3.6.16 TONER
SEPARATION
UNIT
Development unit (
3.6.1)
[A]:
Toner separation unit (
x 3)
B140R954.W
MF
B140R955.
W
MF
[A]
[A]
[B]
[C]
[D]
[E]
218
220
