SM 7
G338/G339
Scanner/
Printer Unit
G338/G339
1.4 USB
1.4.1 PIN
ASSIGNMENT
The controller has a type “B” receptacle (CN10).
Pin No.
Signal Description
Wiring Assignment
1 Power
Red
2 Data
–
White
3 Data
+
Green
4 Power
GND
White
Controller Board
SIMAC
Parallel I/F
IC Card I/F
NVRAM
CN5 (SLOT1)
CN4
CPU
CN1
CN2
USB I/F
Ethernet I/F
(standard for G073 model)
1
2
34
G338D906.
W
MF
1030
1032
