ADF (B140 SERIES/B064 SERIES)
SM
3-135
B064 Series/B140 Series/G126
Replac
ement
Adjustment
3.13.8
ORIGINAL LENGTH SENSORS
[A]:
Open the original tray.
[B]:
Lower cover (
x 4)
[C]:
Original length sensor 1 – B5 (
x 1)
[D]:
Original length sensor 2 – A4 (
x 1)
[E]:
Original length sensor 3 – LG (
x 1)
B140R876.W
MF
[A]
[B]
[C]
[D]
[E]
