Ricoh 4051 Service Manual

B140 SERIES AND G126 SERVICE MODE
SM 4-69 B064 Series/B140 Series/G126
Trouble-
shooting
Z-Folding Unit B660 Jam Codes
No. Location Related SC Code
169 Paper Feed Sensor: Paper Late ---
170 Paper Feed Sensor: Paper Remains ---
171 Fold Timing Sensor: Paper Late ---
172 Fold Timing Sensor: Paper Remains ---
173 Leading Edge Exit Sensor: Paper Late ---
174 Leading Edge Exit Sensor: Paper Remains ---
175 Upper Stopper Path Sensor: Paper Late ---
176 Upper Stopper Path Sensor: Paper Remains ---
177 Lower Exit Sensor: Paper Late ---
178 Lower Exit Sensor: Paper Remains ---
181 Upper Exit Sensor: Paper Late ---
182 Upper Exit Sensor: Paper Remains ---
183 Paper Fold Motor Lock ---
184 Lower Stopper Motor Lock ---
185 Upper Stopper Motor Lock ---
