PAPER FEED
B064 Series/B140 Series/G126
6-90
SM
6.11.3
TRAY AND PAPER LI
FT MECHANISM – TRAY 2,3
Bottom Plate Lift
Tray lift motor [A]
Î
Coupling [B]
Î
Pin [C]
Î
Shaft [D]
Î
Lift arm [E] (under the
bottom plate).
The universal trays (Tray 2,
Tray 3) are not provi
ded with near end sensors. The
pulse count of the tray lift mo
tor is used to signal near end.
B140D972.
W
MF
[A]
[B]
[C]
[D]
[E]
687
689
