DRUM UNIT
SM
3-39
B06
4 Series/B140 Series/G126
Replac
ement
Adjustment
3.6.6
PTL (B140 SERIES ONLY)
OPC drum (
3.6.5)
[A]:
PTL bracket (
x 2)
[B]: PTL
(
x 1)
Reinstallation
•
The shoulder screw [C
] must be atta
ched again at its initial location.
B140R708.W
MF
[A]
[B]
[C]
212
214
