SCANNER
SM
3-15
B06
4 Series/B140 Series/G126
Replac
ement
Adjustment
3.4.5 EXPOSURE
LAMP
Exposure glass (
3.4.2)
Operation panel (
3.3.1)
Push the 1st scanner [A] to the cu
tout [B] in the scanner frame.
[C]:
Exposure lamp cover (
x 2)
[D]:
Exposure lamp (
x 3,
x 1)
NOTE:
Never touch the surface of the
exposure lamp with bare fingers.
B140R912.W
MF
[A]
[B]
[C]
[D]
188
190
