Engine Mechanical: 1D-19
NOTE
The learned value of the ISC valve is set at
RESET position.
6) Close the SDS tool.
7) Turn the ignition switch OFF position.
NOTE
The ISC valve opening initialization is
automatically started after the ignition switch
is turned OFF.
TP Reset
B947H11406016
When replacing the throttle body assembly or TP sensor
with a new one or reinstalling the TP sensor, reset the
TP learned value in the following procedures:
NOTE
Keep the throttle valves fully closed while
resetting the TP learned value.
1) Turn the ignition switch ON.
2) Set up the SDS tool. (Refer to the SDS operation
manual for further details.)
3) Click the “Active control”.
4) Click the “TP learned value reset” (1).
5) Click the “Reset” button (2) to clear the TP learned
value.
NOTE
The leaned value of the TP sensor is set at
Preset position.
6) Close the SDS tool and turn the ignition switch OFF.
I947H1140303-01
1
I947H1140304-01
2
I947H1140305-01
I947H1140306-01
Manuals by Motomatrix / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk / www.motomatrix.co.uk

Suzuki GSX-R1000 Specifications

General

Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Fuel Tank Capacity	16.0 L (4.2 US gal)
Overall Length	2, 075 mm (81.7 in)
Wheelbase	1, 420 mm (55.9 in)
Ground Clearance	130 mm (5.1 in)
Seat Height	825 mm (32.5 in)
Starter	Electric
Final Drive	Chain
Front Brakes Brand	Brembo
Displacement	999.8cc
Bore x Stroke	55.1mm
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Tire	120/70ZR17M/C (58W)
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
