Exhaust System: 1K-2

Exhaust Control System Operation

B947H11B01002

The EXCS is operated by the signal supplied from the ECM. The open/close operation of the EXCV is performed by

the EXCVA which is controlled by the ECM by changing the current direction of the actuator motor. The position

sensor (incorporated in the EXCVA) detects the EXCVA movement by measuring the voltage and then the ECM

determines the EXCV opening angle based on the engine rpm and gear positions. Every time the ignition switch is

turned ON, the EXCVA automatically drives the EXCV and detects full close/open position voltages and sets the

EXCV to middle position.

FULL CLOSE

I947H11B0002-01

Manuals by Motomatrix / The Solution For Lost Motorcycle Coded Keys

email: info@motomatrix.co.uk / www.motomatrix.co.uk

Questions and Answers:

Need help?

Do you have a question about the Suzuki GSX-R1000 and is the answer not in the manual?

Suzuki GSX-R1000 Specifications

General

Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Fuel Tank Capacity	16.0 L (4.2 US gal)
Overall Length	2, 075 mm (81.7 in)
Wheelbase	1, 420 mm (55.9 in)
Ground Clearance	130 mm (5.1 in)
Seat Height	825 mm (32.5 in)
Starter	Electric
Final Drive	Chain
Front Brakes Brand	Brembo
Displacement	999.8cc
Bore x Stroke	55.1mm
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Tire	120/70ZR17M/C (58W)
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
