Maintenance and Lubrication: 0B-22

Special Tools and Equipment

Recommended Service Material

B947H10208001

NOTE

Required service material is also described in the following.

“Lubrication Points” (Page 0B-3)

Special Tool

B947H10208002

Material SUZUKI recommended product or Specification Note

Brake fluid DOT 4 — )(Page 0B-16)

09900–20803 09900–20805

Thickness gauge Tire depth gauge

)(Page 0B-6) )(Page 0B-18)

09915–40610

Oil filter wrench

)(Page 0B-11) /

)(Page 0B-11)
