Suzuki GSX-R1000 User Manual

2D-13 Wheels and Tires:
Rear Wheel Dust Seal / Bearing Removal and
Installation
B947H12406010
Removal
1) Remove the rear wheel assembly. Refer to “Rear
Wheel Assembly Removal and Installation”
(Page 2D-11).
2) Remove the rear sprocket mounting drum assembly
(1) from the rear wheel.
3) Remove the wheel dampers (2).
4) Remove the dust seal.
Special tool
(A): 09913–50121 (Oil seal remover)
5) Remove the bearings on both sides using the special
tool.
Special tool
(B): 09921–20240 (Bearing remover set)
6) Remove the spacer (3).
Installation
CAUTION
!
The removed dust seal and bearings must be
replaced with new ones.
1) Apply grease to the wheel bearings.
: Grease 99000–25010 (SUZUKI SUPER
GREASE “A” or equivalent)
1
I947H1240019-01
2
2
I947H1240020-02
(A)
I947H1240021-01
(B)
(B)
I947H1240022-01
3
I947H1240023-01
I649G1240019-02
Manuals by Motomatrix / The Solution For Lost Motorcycle Coded Keys
email: info@motomatrix.co.uk / www.motomatrix.co.uk

Suzuki GSX-R1000 Specifications

General

Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Fuel Tank Capacity	16.0 L (4.2 US gal)
Overall Length	2, 075 mm (81.7 in)
Wheelbase	1, 420 mm (55.9 in)
Ground Clearance	130 mm (5.1 in)
Seat Height	825 mm (32.5 in)
Starter	Electric
Final Drive	Chain
Front Brakes Brand	Brembo
Displacement	999.8cc
Bore x Stroke	55.1mm
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Front Tire	120/70ZR17M/C (58W)
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
