Suzuki GSX-R1000 User Manual

9B-4 Lighting Systems:
Front Turn Signal Light Removal and
Installation
B947H19206006
Removal
1) Remove the screw.
2) Disconnect the front turn signal coupler (1).
3) Remove the turn signal light assembly (2).
Installation
Install the front turn signal light in the reverse order of
removal.
Front Turn Signal Light Bulb Replacement
B947H19206007
CAUTION
!
When you touch the bulb with your bare
hands, clean the bulb with a cloth moistened
with alcohol or soap water to prevent
premature bulb failure.
1) Remove the turn signal light assembly.
2) Remove the socket (1) by turning it
counterclockwise.
3) Replace the front turn signal light bulb (2).
I947H1920013-01
1
2
I947H1920014-01
1
I947H1920015-01
2
I947H1920016-01
