Body Structure: 9E-3

Side-stand Construction

B947H19506003

(a)

(b)

(a)

I947H1950003-03

1. Frame 3. Washer : 50 N⋅m (5.0 kgf-m, 36.0 lbf-ft) : Apply grease to sliding surface.

2. Side-stand bracket 4. Side-stand : 40 N⋅m (4.0 kgf-m, 29.0 lbf-ft)
