COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
CHAPTER 2 NEW FUNCTIONS
2-69
3.9.12 Removing the Cop
yboard Cover Sensor
1)
Remov
e the reader rear cov
er (See
10.4.1.h.).
2)
Remov
e the three scre
ws [1], and detach
the fuse PCB base [2].
F02-309-22
3)
Disconnect the connector [1], and re-
mov
e the scre
w [2]; then, detach the
copyboard cov
er sensor cov
er [3] and
the copyboard cov
er sensor [4].
F02-309-23
[1]
[2]
[1]
[4]
[2]
[3]
123
125
