Canon iR8500 - E211; E215; E218

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
CHAPTER 6 TROUBLESHOOTING
6-110
4.1.29 E211
4.1.30 E215
Connector
1) Are the connectors J852 and J853 on the light control PCB con-
nected securely?
NO: Connect the connectors securely.
Fluorescent lamp heater
2) Try replacing the fluorescent lamp heater. Is the problem cor-
rected?
YES: End.
Light control PCB, Reader controller PCB
3) Try replacing the light control PCB. Is the problem corrected?
YES: End.
NO: Replace the Reader controller PCB.
4.1.31 E218 (Indicated if iR8500)
Mounting condition
1) Is the fluorescent lamp mounted securely?
NO: Mount it securely.
Connector
2) Are the connectors J1002 and J1003 on the inverter PCB connected
securely?
NO: Connect the connectors securely.
Fluorescent lamp, Reader controller PCB
3) Try replacing the fluorescent lamp. Is the problem corrected?
YES: End.
NO: Replace the reader controller PCB.
4) Is the connector J1702 on the the relay PCB connected properly?
NO: Connect it properly.
