COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
CHAPTER 4 INST
ALLA
TION
4-12
No
.
W
ork
Chec
ks/remarks
1
Open the front cover
.
2
Remove the tape [1] from the front of the
inside cov
er and the tape [3] used to keep
the tag [2] in place.
F04-204-01
Shift down the f
ixing/feeding assembly
releasing lev
er [1] in the direction of the
arrow (left) to unlock the transfer/separa-
tion charging assembly
.
F04-204-02
2.4 Mounting the Fixing Assembly
[1]
[3]
[2]
[1]
