CHAPTER 4 INST
ALLA
TION
4-14
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
2.5 Mounting the Charging Assemb
ly
No
.
W
ork
Checks/remarks
1
Remove the scre
w [2], and detach the
transfer/separation assembly front cov
er
[1].
2
Remove the f
ixing [1] (1 screw [2]), and
disconnect the connector [3].
F04-205-01
F04-205-02
[2]
[1]
[3]
[1]
[2]
314
316
