CHAPTER 4 INSTALLATION
4-27
COPYRIGHT
©
2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
2.11 Index Paper Attachment
No. Work Checks/remarks
1 Decide on either cassette 3 or 4 for use for
index paper.
Press the releasing button for the cassette,
and slide it out to the front.
Peel the backing sheet [2] and the
protective sheet [3] from the attachment
sheet [1], and attach the attachment sheet
to the area [4] indicated in the figure.
2 Place the index paper attachment [5] over
the attachment sheet.
3 Fit the base sheet [6] in the cassette.
Slid out the cassette.
F04-211-01
[2]
[1]
[5]
[4]
[3]
[6]
To Next Page
