COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
CHAPTER 6
TR
OUBLESHOO
TING
6-26
2.4.9 P
osition of the Solenoids
F06-204-11
SL9
SL10
SL7
SL8
SL6
SL11
SL3
SL4
SL2
SL 2
SL 3
SL 8
SL 7
SL 9 / 10
SL 4
SL 11
SL 101
Side paper deck
Solenoid
(SL 2)
Solenoid
(SL 2)
10.5±0.5mm
Solenoid
(SL 4)
Solenoid
(SL 7)
Solenoid
(SL 3)
8.2mm
50±0.5mm
36±0.5mm
34.5±0.5mm
No adjustment needed.
Screws
Solenoid
(SL 101)
0.4±0.2mm
Solenoid
(SL 6)
SL 6
Push fully.
A
If the fixing web is new,
If the fixing web has been in use,
Solenoid
(SL 8)
Solenoid
(SL 9,10)
428
430
