CHAPTER 4 INSTALLATION
4-59
COPYRIGHT
©
2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
4 Relocating the Machine
After installation, if the machine must be relocated by truck or other means of transporta-
tion, perform the following:
No. Work Checks Remarks
A. If stairs are used to move the copier into or out of the user’s place, keep
the following in mind:
1. Take out the fixing/feeding assembly, holding tray, and copy paper
from the copier, and carry them separately (If an ADF is installed, re-
move it also).
2. When lifting the copier, do not use the grips on the pickup/delivery
assembly; instead, support it at four corners of the machine bottom.
B. Shift up the 2 adjusters (front) found on the bottom of the copier, and
check to make sure that they are unlocked. Take care, as the adjusters can
slip out of the machine because of vibration while in transit.
C. Be sure to remove the options (side paper deck, finisher) when moving
the copier into or out of the user’s place.
Check to make sure
that the No. 2 mirror
base does not move.
Carry the develop-
ing assembly in a
separate box.
1 Make a copy in Direct.
2 Take out all paper from all cassette.
3 Turn off the power switch, and disconnect the
power plug from the power outlet.
4 Fix the No. 2 mirror base in place from the left
cover side with scanner fixing.
5 Take out the developing assembly.
6 Tape the transfer charging assembly, fixing/feed-
ing assembly, releasing lever, and lower feeding
assembly in place to protect them against vibra-
tion.
7 Tape the front cover, hopper cover, cassettes, and
right cover (upper, lower) in place.
8 Place A3 copy paper on the copyboard glass, and
tape the ADF in place.
To Next Page
