CHAPTER 4 INST
ALLA
TION
4-57
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
3.9 Connectors
No
.
W
ork
Checks/remarks
1
Connect the cable [1] for the environment
heater
.
2
[If 100V model]
As needed, connect the reader unit anti-
condensation heater cable [1].
F04-309-02
[1]
F04-309-01
[1]
357
359
