CHAPTER 2 NEW FUNCTIONS
2-104
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
6.3.1 Reader Unit
a. Sliding the Reader Unit (iR7200)
1)
Remov
e the
ADF
.
2)
Remov
e the upper right cov
er (inside;
see 10.4.1.j).
3)
Remov
e the rear upper cov
er
.
4)
Remov
e the left upper cov
er
.
5)
Remov
e the screw [2] of the stopper [1].
F02-603-01
6)
Remov
e the 2 screws [1], and slide the
reader unit [2] to the left.
F02-603-02
[1]
[2]
[2]
[1]
158
