CHAPTER 1 INTR
ODUCTION
1-14
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
3 Names of P
ar
t
s
3.1 Exter
nal
Vie
w (iR8500)
F01-301-01
[1]
ADF
[2]
Control panel power switch
[3]
Original deliv
ery tray
[4]
Main po
wer switch
[5]
Manual feed tray
[6]
Right upper cove
r
[7]
Right lo
wer cov
er
[8]
W
aste toner case, Drum protection
sheet case
[9]
Right deck
[10]
Left deck
[11]
Cassette 3
[12]
Cassette 4
[13]
Front cover
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
38
40
