3.3 Troubleshooting Faulty Images
3.3.1 The copy is too light (halftone area)
----------
1) Perform the Image adjustment Basic Procedure. Is the problem cor-
rected?
YES: End.
Scanner (soiling)
2) Does the problem occur only in copy images?
YES: The cause is between the scanner and the CCD. Perform the fol-
lowing once again:
1. Check the standard white plate for dirt.
2. Execute the following in service mode:
COPIER>FUNCTION>CCD>CCD-ADJ.
AE adjustment
3) Make copies in AE mode. Is the density normal?
YES: End.
Developing assembly
4) Are the support members of the developing assembly in firm con-
tact with the drum?
NO: Check how the developing assembly is locked in position.
YES: Check to make sure that the coating of toner on the developing cyl-
inder is even.
Image processing
5) Is the setting of the following in service mode too low:
COPIER>ADJUST>DENS>DEN-ADJ?
YES: Set it to ‘5’.
To Next Page
