CHAPTER 2 NEW FUNCTIONS
2-145
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
8.5.5 Others
a.
Removing the Fixing/Feed Unit
1)
Slide out the fixing/feed unit.
2)
Remov
e the 2 stepped scre
ws [1].
F02-805-25
3)
Remov
e the fixing /feed unit [1] from
the slide rail [2].
Be sure to work as a group of
two.
F02-805-26
[1]
[1]
[2]
[1]
199
201
