CHAPTER 2 NEW FUNCTIONS
2-209
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
10.4.5 Switches
a.
Removing the F
ront Cov
er Switch Assemb
ly
1)
Remov
e the control panel unit (See
10.4.2.a.b
.).
2)
Remov
e the 3 screws [1], and detach the
cov
er switch assembly [2].
F02-1004-57
3)
Disconnect the 3 connectors [1], and
detach the cov
er switch assembly [2].
F02-1004-58
[1]
[1]
[2]
[2]
[1]
263
265
