CHAPTER 4 INST
ALLA
TION
4-44
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
1
Open the front cover
.
2
Remove the tape [1] from the front of the
inside cov
er and the tape [3] used to keep
the tag [2] in place.
F04-304-01
F04-304-02
No
.
W
ork
Checks/remarks
Shift down the f
ixing/feeding assembly
releasing lev
er [4] in the direction of the
arrow (left) to unlock the transfer/
separation charging assembly
.
3.4 Mounting the Fixing Assembly
[1]
[3]
[2]
[4]
344
346
