CHAPTER 2 NEW FUNCTIONS
2-223
COPYRIGHT
©
2001 CANON INC
.
2000 2000 2000 2000
CANON iR8500/7200 REV
.1 A
UG.
2001
[1]
[1]
[2]
10.4.7 Others
a.
Removing the P
ow
er Supply Unit
1)
Remov
e the left lower cov
er (4 scre
ws).
2)
Disconnect the 2 connectors [1], and
disconnect the connector from the relay
PCB [2].
F02-1004-84
3)
Remov
e the 2 screws [1], and detach the
cov
er plate [2]; them, remov
e the 2
screws [3], and detach the po
wer supply
unit [4].
F02-1004-85
[1]
[1]
[2]
[3]
[3]
[4]
