Canon iR8500 - E019

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
CHAPTER 6 TROUBLESHOOTING
6-99
4.1.12 E019
Waste toner case (full)
1) Is the waste toner case full of toner?
YES: Dispose of the toner inside the waste toner case.
Water toner case base
2) Does the waste toner case base move smoothly?
NO: Correct the base.
Connector
3) Is the connector (J514) on the DC controller PCB connected
firmly?
NO: Connect it firmly.
Waste toner full sensor, DC controller PCB
4) Try replacing the waste toner full sensor (PS19). Is the problem cor-
rected?
YES: If the cable connection up to the DC controller PCB is normal, re-
place the waste toner full sensor (PS19).
NO: Replace the DC controller PCB.
