2001 CANON INC. 2000 2000 2000 2000 CANON iR8500/7200 REV.1 AUG. 2001
CHAPTER 6 TROUBLESHOOTING
6-156
5.1.6 Lower Feeding Assembly
----------
1) Is the lower feeding assembly fitted correctly?
NO: Fit the assembly correctly.
Lower feeding middle clutch (CL16), Lower feeding right clutch (CL17)
2) Is the roller inside the lower feeding assembly rotating correctly?
NO: Replace CL16 or CL17.
Pre-confluence sensor (PS14), Post-confluence sensor (PS15)
3) Are the pre-confluence sensor (PS14) and the post-confluence sen-
sor (PS15) normal?
NO: Replace PS14 or PS15.
To Next Page
